1."Ultra-fine vertical roller mill manufacturer utilizes tire-shaped rollers and grinding tables; the roller sleeves are reversible, extending the service life of wear parts and reducing operating costs.

2. "The China ultra-fine vertical mill" is equipped with

 a multi-head powder selector, which has high powder selection accuracy and a content of 2 microns. It is adjustable and

controllable.

3."Zhongyide's Calcium carbonate vertical roller mill" uses high-quality wear-resistant materials for its roller sleeves and liners, such as high-chromium castings, ceramic roller sleeves, and liners.

4.  The hydraulic system equipped on the ultra-fine vertical mill adjusts the pressure based on the material conditions in the grinding zone, ensuring stable and efficient grinding performance.

5. The Vertical ultra-fine grinding mill is equipped with an automatic lubrication system; under normal operating conditions, there is no need to shut down the machine for lubrication, effectively ensuring continuous operation.

6.Vietnamese raw ore—particularly from northern regions such as Yên Bái Province—is characterized by exceptional whiteness (reaching 95%–98%) and high calcium carbonate content (up to 98%). With very low levels of impurities such as iron, silicon, and aluminum, the ore is of superior quality; it requires no complex purification processes and is well-suited for deep processing, thereby enhancing its added value and economic worth.

7. Market Demand: Ultrafine ground calcium carbonate powder is widely used in high-end ultrafine powder sectors—such as plastic masterbatch, papermaking, and coatings—where its addition helps reduce costs.

8. Vietnam enjoys a natural advantage in manufacturing due to lower labor and electricity costs compared to China, Europe, and the United States.

9. Vietnam enjoys a natural advantage in manufacturing due to lower labor and electricity costs compared to China, Europe, and the United States.

Process Flow of the China Ultrafine Vertical Mill

Run-of-mine ore is crushed to a size of less than 10 mm by a jaw crusher or hammer crusher and then fed into the main grinding mill via a variable-frequency belt conveyor or screw conveyor. Inside the mill, the material is crushed and compressed in the roller track zone before moving toward the edge of the grinding table; there, a strong airflow carries it into the multi-head powder classifier. Fine powder meeting specifications travels with the airflow through piping to the finished product collection system, where it is discharged as the final product or proceeds to the next processing stage. Oversized or unqualified particles are returned to the main mill for further grinding.

The ultra-fine vertical grinding mill system primarily consists of the following components

Crushing system: PEX series jaw crusher or HC series hammer crusher.

Feeding system: TD series bucket elevator, screw conveyor, variable-frequency belt conveyor,buffer bin, iron remover,etc.

Main components of the China ultrafine vertical mill: vertical mill main unit, gearbox, multi-head powder classifier, hydraulic station, lubrication station, high-pressure fan, pulse dust collector, piping system, discharge device, and motor.

Electrical control system: electrical control cabinet,PLC central intelligent control system.
